Scott Patron 920 granite black

E-Bike Fully Mountainbike

Article no: 4233636922012

Technical details

Frameset
  • Frame: Alloy Frame, Integrated Suspension Technology, Virtual 4 Link kinematic / Adjustable head angle, Syncros Cable Integration System, Bosch Smart System / UDH Interface / 12x148mm with 55mm Chainline, Bosch PowerMore Ready
  • Fork: RockShox Psylo Silver RC Air / E-Bike / Comp & Reb Adj. / QR Axle 15x110mm axle, 44mm offset / tapered steerer / 150mm travel
  • Shock: X-Fusion NUDE 5 RLX Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Reb. Adj., Travel 150-100-Lockout / T185X55mm
  • Headset: Syncros - Acros Angle adjust & Cable Routing HS System / +-0.6? head angle adjustment, ZS56/28.6 ? ZS56/40 MTB
Drive
  • Rear Derailleur: Shimano Deore RD-M6100 SGS, Shadow Plus / 12 Speed
  • Shifter: Shimano Deore SL-M6100-IR / Rapidfire Plus
  • Number of gears: 12
  • Crankset: FSA Alloy
  • Chain: Shimano CN-M6100
  • Cassette: Shimano CS-M6100 / 10-51
Brakes
  • Brake (front): Shimano MT520 4 Piston Disc
  • Brake (rear): Shimano MT520 4 Piston Disc
  • Brake Discs : Front: Shimano SM-RT64 CL 220mm || Rear: Shimano SM-RT64 CL 203mm
Wheels
  • Front rim: Syncros MD30 / 32H / 30mm / Pin Joint, Tubeless ready
  • Rim rear: Syncros MD30 / 32H / 30mm / Pin Joint, Tubeless ready
  • Tire Front: Maxxis Forekaster 29x2.6", 120TPI Foldable Bead, EXO / TR Tubeless ready, 3C Maxx Terra
  • Tire Rear: Maxxis Forekaster 29x2.6", 120TPI Foldable Bead, EXO / TR Tubeless ready, 3C Maxx Terra
  • Hub Front: Formula CL-811 / 15x110mm
  • Hub Rear: Formula ECT-148M / Boost 148x12mm
  • Spokes: Stainless Black
Equipment
  • Handlebar: Syncros Hixon 2.0 Alloy 6061, Size S & M 15mm rise / Size L & XL 25mm rise / back sweep 8? / 780mm
  • Stem: Syncros AM 2.0, Syncros Cable Integration System, 4? rise / 6061 Alloy / 31.8mm / 1 1/8"
  • Grips: Syncros Endurance lock-on grips
  • Handlebar Remote: SCOTT TracLoc 2 Technology, Suspension & Dropper Remote, 3 modes
  • Saddle: Syncros Tofino-E 2.5 Regular
  • Seat Post: Syncros Duncan Dropper Post 2.5, 31.6mm / S size 125mm / M size 150mm / L size 170mm / XL size 200mm
  • Front Light: Front Light Cable pre-installed
  • Rear Light: Syncros integrated rear fender light
E-Bike System
  • Drive Unit: Bosch Performance CX, EU: 25kmh / INT: 20mph
  • Battery: PowerTube 800Wh
  • Display: Bosch System Controller, Mini Remote & Intuvia 100
  • Charger: 4A Charger
Additional Information
  • Weight (KG): 25,8
  • Maximum weight allowed: 128

Info: Unless otherwise described, this item will be delivered by a forwarding agent “free kerbside”, i.e. to the public kerbside nearest to the delivery address.
