Article no: 803120
€4,084.05*
- 5%RRP: €4,299.00*
previously €4,084.058
incl. VAT | Free shipping
Choose color
Simple, secure payment
30 days money back
Individual advice
Please note!
Pedals are not included with this bike.
Passendes Zubehör
Technical details
Frameset
- Frame: C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing
- Size: S, M, L, XL
- Fork: SR Suntour Aion 38X 2CR Air, Tapered, 15x110mm, Lockout, 170mm
- Shock: SR Suntour Edge EVO 2CR 230x65mm
- Shock Hardware: Front: 30x8mm, Rear: DU-Bushing 12,7mm
- Headset: ACROS AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), Fiber Inserts for Angle Adjustment
Equipment
- Stem: CUBE Performance Stem E-MTB 35, FPI-Link
- Handlebar: CUBE Rise Trail Bar 35
- Grips: ACID Disrupt, Soft Compound
- Saddle: ACID Venec Lite
- Seat Post: CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
- Seat Post Clamp: CUBE Semi-Integrated
Drive
- Rear Derailleur: Shimano Deore RD-M6100-SGS, ShadowPlus, 12-Speed
- Chain Guide: Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
- Shifter: Shimano Deore SL-M6100, Rapidfire-Plus
- Crankset: ACID MTB Hybrid Pro, 36T
- Cassette: Shimano Deore CS-M6100, 10-51T
- Chain: KMC e12
Brakes
- Brakes: Magura MT Thirty, Front 4-Piston/Rear 4-Piston, Hydr. Disc Brake (203/203)
Wheels
- Rims: CUBE EX30, 32H, Disc, Tubeless Ready
- Hub Front: CUBE Engineered By Newmen, 15mm, Boost, 6-Bolt
- Hub Rear: CUBE Engineered By Newmen, 12mm, Boost, 6-Bolt
- Tire Front: Schwalbe Magic Mary, Performance, 2.4
- Tire Rear: Schwalbe Big Betty, Performance, 2.4
E-Bike System
- Drive Unit: Bosch Drive Unit Performance Line CX 85Nm (BDU38), Smart System
- Battery: Bosch PowerTube 800
- Charger: Bosch 2A
- Remote System: Bosch System Control, incl. Mini Remote
Additional Information
- Color: dazzle´n´black
- Weight (KG): 25,2 kg
- Maximum weight allowed: 150 kg
Info: Unless otherwise described, this item will be delivered by a forwarding agent “free kerbside”, i.e. to the public kerbside nearest to the delivery address.
